340LPH @ 40 psi - Inline Inlet - E85 Compatible

---

AEM's 340LPH E85-Compatible High Flow In-Tank Fuel Pumps feature robust internal construction that is designed to withstand the low lubricity characteristics of ethanol and methanol fuels, and are tested to work with ethanol fuels up to E100, methanol fuels up to M100 and all types of gasoline.The AEM 340LPH E85-Compatible High Flow In-Tank Fuel Pump is designed for in-tank mounting on high performance naturally aspirated and forced induction vehicles. It features a compact 39mm diameter that fits most applications and an offset inlet design that eases installation.The 340LPH E85-Compatible High Flow In-Tank fuel pump includes a wiring harness, pre filter, end cap and rubber buffer sleeve. Every AEM 340LPH E85-Compatible Fuel Pump is tested to flow 340 lph at 40 PSI before it is packaged for sale.TECHNICAL SPECS:Weight: 12.5oz (354grams)Outside Diameter: 39mm ODExternal Materials: Black plated steel with laser etchingInlet Fitting: 7.7mm ID, 11.0mm OD. Offset InlineOutlet Fitting: 8 mm hose clamp. OffsetPRV Activation: 80 PSIImpeller Design: Single Scroll Ceramic TurbineVOLTAGE SPECS:Connector Terminal: 6 mm Spade (pos/neg)Min Voltage Input: 6 voltsMax Voltage Input: 18 voltsCurrent Draw (40 psi): 12 amps (13.5v)Current Draw (80 psi): 15 amps (13.5v)Fuse: 20 amps (13.5v)* Power rating given at 43 PSI, 13.5v at the pump terminal with a BSFC of .5. Flow capability for horsepower support is ultimately dependent on fuel hose diameter, and system electrical voltage and amperage capabilities.

• Tested and compatible with ethanol fuels up to E100, methanol fuels up to M100 and all types of gasoline
• Designed for high output naturally aspirated and forced induction EFI vehicles
• Tested to flow 340 lph @ 40 PSI
• 39mm diameter fits most applications
• Offset inlet design eases installation
• Each pump individually tested
• Kit includes fuel pump, rubber sleeve and end caps, pre filter and flying lead
• In tank design

---

Information:

Although AEM's High Flow Fuel Pumps are the same physical size as many OEM fuel pumps, they may not be appropriate for a specific application. You can consult the Vehicle Search function on our website to see whether a pump is recommended for your vehicle. The Vehicle Search function should be used as a reference only. It is imperative that you check the fuel pump sizing for your vehicle before purchasing an AEM High Flow Fuel Pump. AEM does not condone or approve of the modification of a tank to accommodate a High Flow Fuel Pump and cannot guarantee the pump's performance or operation if any modifications are made.

---

Application Summary:

Year	Make/Model
1992-2001	Acura Integra
2002-2006	Acura RSX
1994-2002	Honda Accord
2000-2005	Honda Civic
2000-2009	Honda S2000
2003-2007	Mitsubishi Lancer
2013-2015	Scion FR-S
2010	Scion tC
2004-2006	Scion xA
2004-2006	Scion xB
2013-2015	Subaru BRZ
2004-2007	Subaru Forester
2002-2007	Subaru Impreza
1992-2002	Toyota 4Runner
1995-1999	Toyota Avalon
1992-2006	Toyota Camry
1994-2005	Toyota Celica
2000-2005	Toyota Echo
2001-2003	Toyota Highlander
2003-2006	Toyota Matrix
2000-2005	Toyota MR2 Spyder
1992-1998	Toyota Paseo
1992-1995	Toyota Pickup
1994-1995	Toyota Previa
1996-2005	Toyota RAV4
1998-2000	Toyota Sienna
1999-2006	Toyota Solara
1993-1998	Toyota T100
1995-2004	Toyota Tacoma
1990-1998	Toyota Tercel
