This Reflex 5550 Series LED Minibar (2.2"H x 10.9"W x 7.6"D, 3.4 amps) has 4 LED reflector modules with 12 LEDs, 27 flash patterns, amber single-color illumination, an amber low-profile lens, a vacuum mount, & a polycarbonate base.

---

5550 Series LED microbars provide a super-compact yet powerful warning solution that offers the flexibility of either permanent or vacuum-magnet mounting. Featuring 12-24 VDC operation, the Reflex microbar uses high intensity LEDs to maximize light output. Users can select from 27 flash patterns, either via trigger wire on permanent mount models or cigarette plug switch on vacuum-magnet models.

• Reflex Series; Vacuum-Magnet Mount; 12-24V; 3.4 amps; 27 Flash Pattern; SAE Class I/CA Title 13/CE/R10/RCM/IP65/RoHS; 2.2"H; 10.9"W; 7.6"D; 4 LED reflector mods w/12 LEDs; Cig plug power/flash pattern switch; Polycarbonate base; Low profile

---

Information:

Reflex Series; Amber Single-Color Illumination; Amber Dome Color; Vacuum-Magnet Mount; Zero Optic Dome; 12-24 V; 3.4 amps; 27 Flash Pattern; Approval Ratings: SAE J845 Class I, California Title 13, CE, R10, RCM, IP65, R65, RoHS; 2.2" height x 10.9" width x 7.6" depth; Four LED reflector modules, each containing 12 LEDs provide high intensity light output; Choice of 27 flash patterns: Quad flash, Double flash, Fast double, Slow quad, Slow double, Quint-hold, Burst, Alternate Side-to-Side Quad, Diagonal Alternate Quad, Alternate Side-to-Side Double, Diagonal Alternate Double, Alternate Side-to-Side Quint-hold, Diagonal Alternate Quint-hold, Fast rotate, Rotate/quad, Wave rotate, Random, Steady on; Cigarette plug with on/off and flash pattern selection switch (vacuum-magnet); Polycarbonate base & low profile lens; Syncable with existing Reflex line of minibars; Temperature Range: -22°F to +122°F (-30°C to +50°C); Replacement Parts: PN: R5545LA Amber Dome and PN: R5545LC Clear Dome.
