Edelbrock Performer RPM Q-Jet Intake Manifold for Chevrolet 396-502 Big-Block V8
Edelbrock part #7164 Performer RPM Q-Jet intake manifold is designed for street 396-502 c.i.d. Chevy V8's with large oval-port (1975 and earlier) heads. This intake manifold is designed works with spread-bore carbs, but also works with Edelbrock square-bore carbs without adapter. No provisions for hot air style chokes. Accepts divorced choke, late-model waterneck, air-conditioning, alternator and HEI equipment.
Application Summary:
| Year |
Make/Model |
| Chevrolet:Big-Block |
Mark IV:396 (6.6L)/402 (6.6L)/427 (7.0L)/454 (7.4L)/502 (8.2L) |
| Attributes |
| ASIN |
B00062YBF2 |
| Basic Operating RPM Range |
1500-6500 |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Center Maximum Height |
5.220, 5.22, 5.220 |
| CNC Ported |
No |
| Country of Origin (Primary) |
US |
| Cylinder Head Type |
Oval Port- Large |
| EGR Port |
No - For Oval Port |
| Emission |
Without EGR |
| Emission Code |
Not in CA |
| Engine Make/Size |
Chevy Big Block (396-502) |
| Finish |
Satin |
| Flange Type |
4150 |
| Front Maximum Height |
4.450, 4.45, 4.450 |
| Gasket Or Seal Included |
No, No, No |
| Grade Type |
Performance, Performance, Performance |
| Harmonized Tariff Code (Schedule B) |
8708998175 |
| Hazardous Material Code |
N |
| Life Cycle Status Code |
Available to Order |
| Material |
Aluminum |
| NAFTA Preference Criterion Code |
B |
| Number of Carbs |
One |
| Position |
N/A |
| Potential Risk Chemical |
Lead |
| Rear Maximum Height |
6.000, 6, 6.000 |
| RGL |
WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov., WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| RPM Range |
1500-6500 |
| SDR Required Flag |
N |
| SDS Sheet Number |
NA |
| Series |
Performer RPM, Performer RPM |
| Single Or Dual Plane Type |
Dual Plane, Dual Plane, Dual |
| Usage |
Street/Hi-Performance |
| Vehicle Model |
Chevrolet, Chevrolet |
| Warranty Time |
12 |
| GTIN |
00085347071647 |
