Edelbrock RPM Air-Gap 460 Intake Manifold for Ford 429/460 Big-Block V8
Edelbrock part #7566 RPM Air-Gap 460 intake manifold is designed for street and high performance 429/460+ c.i.d. Ford V8's with standard or Cobra Jet heads. The RPM Air-Gap 460 incorporates the same race-winning design that's been used on our Victor Series competition intakes for decades. The Air-Gap design features an open air space that separates the runners from the hot engine oil resulting in a cooler, denser charge for more power. It also features a larger cross sectional area (3.3 square inches) than the Performer RPM 460 manifold #7166 intake manifold for even more power in high performance and large displacement engines. The carb mount flange accepts both square-bore and spread-bore carbs for Cobra Jet applications. Will not fit 1988 and later models. Note: Early Cobra Jets came with Quadrajets.
Application Summary:
| Year |
Make/Model |
| Ford:Big-Block:429 |
(7.0L )-460 (7.5L) |
| Attributes |
| ASIN |
B000CN70PS |
| Basic Operating RPM Range |
1500-6500 |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Center Maximum Height |
5.480, 5.48, 5.480 |
| CNC Ported |
No |
| Country of Origin (Primary) |
US |
| Cylinder Head Type |
Standard |
| EGR Port |
No |
| Emission |
Without EGR |
| Emission Code |
Not in CA |
| Engine Make/Size |
Ford 429-460 |
| Finish |
Satin, Satin, Satin |
| Flange Type |
4150 |
| Front Maximum Height |
4.810, 4.81 |
| Gasket Or Seal Included |
No, No, No |
| Grade Type |
Performance |
| Harmonized Tariff Code (Schedule B) |
8708998175 |
| Hazardous Material Code |
N |
| Life Cycle Status Code |
Available to Order |
| Material |
Aluminum, Aluminum, Aluminum |
| NAFTA Preference Criterion Code |
B |
| Number of Carbs |
One |
| Position |
N/A |
| Potential Risk Chemical |
Lead |
| Rear Maximum Height |
6.150, 6.15, 6.150 |
| RGL |
WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov., WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| RPM Range |
1500-6500 |
| SDR Required Flag |
N |
| SDS Sheet Number |
NA |
| Series |
RPM Air-Gap, RPM Air-Gap |
| Single Or Dual Plane Type |
Dual Plane, Dual Plane, Dual |
| Usage |
Street/Hi-Performance |
| Vehicle Model |
Ford, Ford |
| Warranty Time |
12 |
| GTIN |
00085347075669 |
