Intake Manifold 1957-1986 262ci-400ci, 1987-later with Aluminum Heads
The new single plane intake manifold is designed to provide a broad RPM powerband for high-performance street/strip engine applications to a maximum engine speed of 7500 RPM. The carburetor-mounting pad is designed to accept all stock or aftermarket square-bore carburetors with manual or electric chokes. These intake manifolds are designed to accept most stock hardware and accessory brackets, but offer performance features, like an updated plenum divider area, a 1" shorter height than the 300-25 manifold, and a choice of two distributor clamp locations. The isolated design of the air/fuel passages helps to increase charge air density and performance.
The new single plane intake manifold is designed to provide a broad RPM powerband for high-performance street/strip engine applications to a maximum engine speed of 7500 RPM. The carburetor-mounting pad is designed to accept all stock or aftermarket square-bore carburetors with manual or electric chokes. These intake manifolds are designed to accept most stock hardware and accessory brackets, but offer performance features, like an updated plenum divider area, a 1" shorter height than the 300-25 manifold, and a choice of two distributor clamp locations. The isolated design of the air/fuel passages helps to increase charge air density and performance.
- Power band: 2500-7500 RPM
- Square Bore Carburetor Mounting Flange
- Isolated Water cross-over
- Port Size: 1.92” height 1.20" width
- Height: Front 4.18", Rear 5.28"
- Single Plane with Isolated Plenum
Information:
Modification to the valve covers may be required when this manifold is used with some types of cylinder heads.Application Summary:
| Year | Make/Model |
|---|---|
| 1965-1974 | Avanti II |
| 1976-1985 | Avanti II |
| 1977-1981 | Buick Century |
| 1978 | Buick LeSabre |
| 1982 | Buick LeSabre |
| 1977-1986 | Buick Regal |
| 1977-1979 | Buick Skylark |
| 1966-1974 | Checker Aerobus |
| 1969-1970 | Checker Deluxe |
| 1965-1982 | Checker Marathon |
| 1969-1974 | Checker Taxicab |
| 1959 | Chevrolet 3B |
| 1959 | Chevrolet 3C |
| 1959 | Chevrolet 3D |
| 1959 | Chevrolet 3E |
| 1959 | Chevrolet 3F |
| 1959 | Chevrolet 3G |
| 1955-1975 | Chevrolet Bel Air |
| 1981 | Chevrolet Bel Air |
| 1958-1972 | Chevrolet Biscayne |
| 1969-1974 | Chevrolet Blazer |
| 1958-1961 | Chevrolet Brookwood |
| 1969-1972 | Chevrolet Brookwood |
| 1975-1986 | Chevrolet C10 |
| 1960-1974 | Chevrolet C10 Pickup |
| 1967-1986 | Chevrolet C10 Suburban |
| 1975-1986 | Chevrolet C20 |
| 1960-1974 | Chevrolet C20 Pickup |
| 1967-1986 | Chevrolet C20 Suburban |
| 1975-1986 | Chevrolet C30 |
| 1960-1974 | Chevrolet C30 Pickup |
| 1960-1962 | Chevrolet C40 |
| 1967-1986 | Chevrolet Camaro |
| 1966-1986 | Chevrolet Caprice |
| 1964-1973 | Chevrolet Chevelle |
| 1963-1968 | Chevrolet Chevy II |
| 1955-1982 | Chevrolet Corvette |
| 1984-1986 | Chevrolet Corvette |
| 1957-1958 | Chevrolet Del Ray |
| 1959-1960 | Chevrolet El Camino |
| 1964-1986 | Chevrolet El Camino |
| 1969-1970 | Chevrolet Estate |
| 1975-1986 | Chevrolet G10 |
| 1968-1974 | Chevrolet G10 Van |
| 1975-1986 | Chevrolet G20 |
| 1967-1974 | Chevrolet G20 Van |
| 1975-1986 | Chevrolet G30 |
| 1970-1974 | Chevrolet G30 Van |
| 1958-1985 | Chevrolet Impala |
| 1975-1986 | Chevrolet K10 |
| 1960-1974 | Chevrolet K10 Pickup |
| 1967-1986 | Chevrolet K10 Suburban |
| 1975-1986 | Chevrolet K20 |
| 1967 | Chevrolet K20 Panel |
| 1960-1974 | Chevrolet K20 Pickup |
| 1967-1986 | Chevrolet K20 Suburban |
| 1977-1986 | Chevrolet K30 |
| 1968-1974 | Chevrolet K30 Pickup |
| 1975-1986 | Chevrolet K5 Blazer |
| 1959-1961 | Chevrolet Kingswood |
| 1969-1972 | Chevrolet Kingswood |
| 1973-1976 | Chevrolet Laguna |
| 1964-1967 | Chevrolet Malibu |
| 1973-1983 | Chevrolet Malibu |
| 1970-1986 | Chevrolet Monte Carlo |
| 1975-1979 | Chevrolet Monza |
| 1955-1961 | Chevrolet Nomad |
| 1969-1979 | Chevrolet Nova |
| 1955-1957 | Chevrolet One-Fifty Series |
| 1959-1961 | Chevrolet Parkwood |
| 1955-1958 | Chevrolet Sedan Delivery |
| 1955-1966 | Chevrolet Suburban |
| Attributes | |
| Barrel | Four |
| Barrels | 4, 4 |
| Basic Operating RPM Range | 2500-7500 |
| Brand | Holley, Holley |
| California Proposition 65 | No |
| Carburetor Flange | 4150 Square Bore |
| Category | Intake Manifolds, Air and Fuel Delivery |
| Category Filter | Intake Manifolds |
| Clearance Category | Intake Manifolds |
| CNC Ported | No |
| Color | Natural, Natural |
| Construction | Cast, Cast |
| Country of Origin (Primary) | CN |
| Cylinder Head Port Shape | Rectangle |
| Cylinder Head Type | Standard |
| Deck Height | 9.025 |
| EGR Port | No, No |
| Emission | N/A |
| Emission Code | 3, 3, Off Road |
| Engine | Chevy Small Block V8, Chevrolet Small Block Gen I |
| Engine Make/Size | Chevy Small Block V8 |
| Finish | Satin |
| Flange Style | 4150 Square Bore |
| Front Height | 4.180 in., 4.18" |
| Front Maximum Height | 4.18, 4.18 |
| Fuel Injectors Included | No, No |
| Fuel System Type | Carb, Carb |
| Gasket Or Seal Included | No, No |
| Grade Type | Performance, Performance |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Manifold Type | High Rise, High Rise |
| Material | Aluminum, Aluminum |
| NAFTA Preference Criterion Code | B |
| Number of Carbs | One |
| Part Type | Engine Intake Manifold, Engine Intake Manifold |
| Plenum Finish | Natural, Natural |
| Position | Upper |
| Product Type | Manifold, Intake Manifold |
| Rear Height | 5.280 in., 5.28" |
| Rear Maximum Height | 5.28, 5.28 |
| RPM Power Band | 2500-7500 RPM |
| RPM Range | 2500-7500 |
| Sale Category | Air and Fuel Delivery |
| SDR Required Flag | N |
| Single Or Dual Plane Type | Single Plane, Single Plane |
| Sub Category | Cylinder Block Components, Cylinder Block Components |
| Throttle Body Bore Diameter | 3.6 |
| Throttle Body Gasket Included | No |
| Usage | Racing |
| Vacuum Ports | Yes |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| GTIN | 00090127052136 |
