Fits 1988-1998 GMT400 C/K Series Trucks
The flange has a 6AN o-ring outlet and return port making the plumbing connections easy. The kit includes the assembled module, a new filter sock, flange o-ring, and the lock ring to complete your installation into your stock fuel tank. The 6061-T6 module flange has been anodized in a bright dip black finish that not only looks great but will also protect from undercar corrosion.
- 6061-T6 billet aluminum flange, anodized black
- 525 LPH pump flow at 60psi and 13.5 volts / 16.9 amp draw
- Capable of supporting EFI engines producing up to 1200 HP
- Fuel sending unit designed to work with the factory gauges
- 6 ORB outlet and return ports
- 8 ORB vent port
- 1/8" NPT evap port
- Includes filter, o-ring, and fuel tank lock ring
Information:
Both EFI and carbureted systems will need a bypass design regulator; we recommend the 12-879 or 12-880 bypass regulators for these installations.
Application Summary:
| Year |
Make/Model |
| 1988 |
Chevrolet C15 |
| 1988-1998 |
Chevrolet C1500 |
| 1988-1998 |
Chevrolet C2500 |
| 1988-1998 |
Chevrolet C3500 |
| 1988-1998 |
Chevrolet K1500 |
| 1988-1998 |
Chevrolet K2500 |
| 1988-1998 |
Chevrolet K3500 |
| 1988-1998 |
GMC C1500 |
| 1988-1998 |
GMC C2500 |
| 1988-1998 |
GMC C3500 |
| 1988-1998 |
GMC K1500 |
| 1988-1998 |
GMC K2500 |
| 1988-1998 |
GMC K3500 |
| Attributes |
| Application |
1988-1998 GM C/K Trucks |
| Brand |
Holley EFI |
| Category |
Air and Fuel Delivery |
| Country of Origin (Primary) |
US |
| Emission Code |
5, 5 |
| Free Flow GPH |
525 |
| Free Flow LPH |
525, 525 |
| Fuel Filter Included |
No |
| Fuel Sending Unit Included |
Yes |
| Fuel Tank Pressure Sensor Included |
No |
| Fuel Type |
Gasoline/E85 Compatible, Gasoline/E85 Compatible |
| Gasket Or Seal Included |
Yes |
| Grade Type |
Performance |
| Harmonized Tariff Code (Schedule B) |
8409915085 |
| Hazardous Material Code |
N |
| In Tank or External |
In Tank |
| Inlet Quantity |
One, One |
| Installation Warnings |
Yes |
| Life Cycle Status Code |
Available to Order |
| Lock Ring Included |
Yes |
| Material |
6061-T6 Aluminum, 6061-T6 Aluminum |
| Maximum Flow Rating |
525, 525 LPH |
| Mounting Hardware Included |
Yes |
| Negative Ground |
Yes |
| Outlet Quantity |
One, One |
| Outlet Type |
AN |
| Part Type |
Fuel Pump Module Assembly |
| Product Type |
Fuel Pump Module, Fuel Pump Module |
| Pump Type |
Electric |
| Regulator Included |
No |
| Sale Category |
Air and Fuel Delivery |
| SDR Required Flag |
N |
| Strainer Included |
No |
| Sub Category |
Fuel Pumps and Related Components |
| Universal Or Specific Fit |
Specific |
| Warning |
California Proposition 65, California Proposition 65 |
| Warranty |
Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| GTIN |
00090127122266 |
